Description

This 1.44 inch TFT LCD Color Screen Module offers vibrant visuals and easy integration for your projects. It features a SPI interface for communication, making it compatible with a wide range of microcontrollers. With a resolution of [Insert Resolution Here], it delivers clear and crisp images, perfect for displaying text, graphics, and even small videos. Its compact size makes it ideal for embedded applications where space is limited. The module is easy to use and comes with necessary documentation and libraries to get you started quickly. Whether you’re building a custom display, creating a user interface, or working on a DIY electronics project, this TFT LCD module is a reliable and versatile choice.

This lovely little display breakout is the best way to add a small, colorful and bright display to any project. Since the display uses 4-wire SPI to communicate and has its own pixel-addressable frame buffer, it can be used with every kind of microcontroller. Even a very small one with low memory and few pins available!

The 1.44″ display has 128×128 color pixels. Unlike the low cost “Nokia 6110” and similar LCD displays, which are CSTN type and thus have poor color and slow refresh, this display is a true TFT! The TFT driver (ST7735R) can display full 16-bit color using our library code.

This 1.44 inch TFT LCD Color Screen Module SPI Interface has 128 x 128 resolution and 262 colors, it uses SPI interface to communicate with the controller such as Arduino, it is the best upgrading of the Nokia5110.

The breakout has the TFT display soldered on (it uses a delicate flex-circuit connector) as well as an ultra-low-dropout 3.3V regulator and a 3/5V level shifter so you can use it with 3.3V or 5V power and logic.

Features :

1. TFT color screen, the effect is far better than other small CSTN screen
2. Fully compatible and alternative 5110 interface
3. Onboard LDO, support 5V/3.3V input voltage

Useful Links:

TFT LCD Technology

Package Includes :

1 x 1.44 inch TFT LCD Color Screen Module
