Description

The SN74HC00N IC is a Quad 2-input NAND gate from Texas Instruments, housed in a PDIP-14 package. It features 4 gates, with Schmitt trigger inputs for improved noise immunity, making it ideal for high-speed digital circuits. Operating with a supply voltage range of 2V to 6V, this IC provides reliable logic functions and is suitable for applications where low power consumption and high-speed operation are required. It can drive output currents of 5.2 mA (low) and -5.2 mA (high) with a propagation delay time of just 8 ns. This IC operates within a temperature range of -40°C to +85°C and provides an operating supply current of only 20 µA at 5V.
Note:
1. Product Images are shown for illustrative purposes only and may differ from the actual product.
2. For Technical Specifications about the IC go through the Datasheet in the Attachment section.

________________________________________
Features :
1. Logic Function: Quad 2-input NAND gate
2. Supply Voltage: 2V to 6V
3. Propagation Delay: 8 ns
4. Output Drive: 5.2 mA (low), -5.2 mA (high)
5. Temperature Range: -40°C to +85°C
6. Operating Supply Current: 20 µA at 5V
________________________________________
Package Includes:
1 x 74HC273D,653 – Octal D-type Flip-Flop Reset Positive-edge Trigger IC DIP-14 Package
IC Type: Gate IC
Gate IC Type: NAND
Operating Temperature (°C) -40°C to +85°C
Supply Current (A) 20 µA
Propagation Delay 8 ns
Shipping Weight 0.001 kg
Shipping Dimensions 4 × 4 × 1 cm
